350kVA
Cummins/NTA855-G1B
Cummins 350 kVA
The 14-litre Cummins that mills and factories run shift after shift.
- Phase
- 3-Ph
- Fuel
- Diesel
- Noise
- 79 dB
Price
On request
01/Open set
- Output
- 500 kVA
- Phase
- 3-Phase
- Noise
- 78 dB
Heavy / Prime
Cummins QSZ13-G3Cummins 500 kVA diesel generator
Main-grid replacement for a plant that runs three shifts.
Price
On request
The figure depends on the canopy and ATS specification, the installation scope and the exchange rate on the day — so we quote it line by line instead of publishing a number that is wrong by the time you read it. Most quotes go out the same day. What decides the price
0301-4521500Best suited to
- Industrial estates
- Large textile mills
- Data centres
- Hospitals
Capabilities
What this set does.
- Prime-rated for continuous industrial duty rather than occasional standby
- Handles the full starting profile of a heavy plant without sequencing the load
- Around 9 hours per tank at 75% load, normally run from a bulk tank
- Full protection and synchronising suite for parallel or mains-paralleled operation
- Remote telemetry with fuel alerting, runtime logging and service scheduling
Specifications
The full sheet.
- Rated output
- 500 kVA / 400 kW
- Phase
- Three phase
- Voltage
- 400V / 230V
- Frequency
- 50 Hz
- Speed
- 1500 rpm
- Fuel
- Diesel
- Engine brand
- Cummins (United States)
- Engine
- Cummins QSZ13-G3 · 6-cylinder turbo aftercooled
- Engine rated power
- 448 kW
- Alternator
- Stamford-type brushless, PMG excited, IP23
- Full-load current
- 720 A per phase
- Fuel tank
- 900 L
- Fuel consumption
- 90 L/h at 75% load
- Noise level
- 78 dB(A) at 7 m
- Enclosure
- Silent canopy
- Starting
- Auto start
- Dimensions (L×W×H)
- 5100 × 1750 × 2450 mm
- Dry weight
- 6800 kg
- Warranty
- 24 months
Next step
A free site survey, an honest recommendation on rating, and an itemised quote with nothing buried in it. No obligation either way.
